Shasta Dam, CA

      Site ID:     std
      Latitude:     40.715800 N
      Longitude:     -122.429300 W
      Elevation:     202 meters
      Active:     Y
      Site Table:     Site Table
      Data:     Realtime Display

Instrument Name     Project Name     Install Date     Data Types
Datalogger CR800     Hydrometeorology Testbed - West     2012-02-02          view
FMCW Precipitation Profiler Digital     Hydrometeorology Testbed - West     2009-12-09          view
GpsTrimble NetRS     Hydrometeorology Testbed - West     2009-12-09          view
Pressure - PTB110B     Hydrometeorology Testbed - West     2009-12-09          view
Temp/RH HMP45C     Hydrometeorology Testbed - West     2009-12-09          view
Tipping Bucket TE525     Hydrometeorology Testbed - West     2009-12-09          view

Instrument Name     Project Name     Install Date     Removal Date     Data Types
Wind Speed and Direction 5103     Hydrometeorology Testbed - West     2012-02-02     2017-10-17          view
Disdrometer Parsivel Optical     Hydrometeorology Testbed - West     2012-02-02     2015-04-28          view

  OutageID     SiteID     Failure Type     Start Date      End Date      Description     Resolution Description
815 std Power Failure 2022-05-19 19:00:00 2022-05-13 15:15:00 Possible site power outage; UPS battery capacity at 0% Power restored; UPS output enabled remotely
810 std Communication - Other 2022-04-04 12:00:00 2022-04-27 23:15:00 Possible satellite hardware communications failure Satellite-communication hardware upgraded
730 std Hardware - PC 2020-07-09 15:00:00 2021-11-18 18:00:00 Radar hardware issues; data acquisition has been disabled until the hardware issues are resolved PC and radar interface cards replaced
726 std Power Failure 2020-06-26 00:00:00 2020-07-02 18:00:00 Power outage due to site maintenance Power restored
707 std Hardware - Instrument 2020-03-15 00:00:00 2020-04-02 23:32:00 Tipping bucket precipitation gauge malfunction; precipitation not being detected Heater wires were interfering with tipping mechanism
671 std Power Failure 2019-11-25 01:34:00 2019-12-05 17:00:00 Can't connect to router Power restored; UPS batteries are failing
642 std Communication - Satellite 2019-07-30 14:58:00 2019-08-08 15:00:00 Can't connect to satellite modem. Site lost power on 2019-07-30 14:58:00 UTC and UPS turned off after battery voltage dropped too low. UPS did not turn back on after batteries were recharged. Remote UPS login was successful on 2019-8-8 15:00:00 UTC, and UPS was manually turned on.
501 std Communication - Satellite 2016-08-06 00:00:00 2016-08-10 00:00:00 Satellite modem unresponsive. Could be a power failure, modem issue, phone line issue, or comms computer issue. Modem came back after reboot.
485 std Communication - Satellite 2016-04-06 05:00:00 2016-04-08 00:00:00 Unable to reach radar PC. System needed to be rebooted.
456 std Communication - Satellite 2015-06-15 12:00:00 2015-06-22 23:00:00 Modem unresponsive. Could be a power failure, modem issue, phone line issue, or comms computer issue. Shasta connection restored.
447 std Communication - Satellite 2015-04-16 01:00:00 2015-04-28 00:00:00 Unable to reach router/PC PC was in hung state. Rebooted machine.
445 std Communication - Satellite 2015-02-19 02:00:00 2015-03-06 22:00:00 Unable to reach satellite router. Could be power, satellite and/or PC issue. Computer was off. Had to power back on.
411 std Hardware - Instrument 2014-10-24 00:00:00 2014-11-24 00:00:00 Parisvel shut down since comms are intermittent. Need to replace all connection cable and/or parivel unit on next site visit. Parsivel will be left running as is for season.
405 std Communication - Satellite 2014-10-04 00:00:00 2014-10-07 00:00:00 Satellite router unresponsive. Could be a power failure, router issue or comms computer issue. Satellite system was in a unresponsive state. Power cycle returned normal healthy state.
390 std Hardware - Instrument 2014-06-11 00:00:00 2014-10-06 00:00:00 Parsivel unresponsive. Tried cycling power and it did not reset. Update 7/7/14 Unable to connect to datalogger. Tried rebooting machine. Swapped Parsivel.
271 std Communication - Satellite 2012-11-09 12:00:00 2012-11-28 17:00:00 Satellite router unresponsive. Could be a power failure, router issue or comms computer issue. Update 11/19/12. Contact could not talk to Hughes modem locally. Problem with sat system. System power cycled.
199 std Communication - Satellite 2012-03-13 03:00:00 2012-03-13 03:00:00 Satellite router unresponsive. Could be a power failure, router issue or comms computer issue. Most likely weather related issue given current storm conditions (3/13/12 - 14z) Communications returned.
115 std Communication - Phone 2011-07-07 15:00:00 2011-07-09 00:00:00 Modem unresponsive. Could be a power failure, modem issue, phone line issue, or comms computer issue. Computer rebooted.
86 std Communication - Phone 2011-04-23 17:00:00 2011-04-26 16:00:00 Modem unresponsive. Could be a power failure, modem, phone line, or PC issue. Contact at Shasta power cycled the PC. Hung modem was the issue due to noisy phone line.
78 std Communication - Phone 2011-03-25 23:00:00 2011-03-25 16:00:00 Modem unresponsive. Could be a power failure, modem, phone line, or PC issue. Modem connection restored. Was a hung modem on field machine.
56 std Hardware - PC 2011-03-12 18:00:00 2011-03-17 18:00:00 Hardware PC error. Failure writing to USB device causing POP not to run correctly. Site visit planned for 3/17/11. Problem fixed on site by staff.
37 std Communication - Phone 2011-02-17 02:00:00 2011-02-25 23:00:00 Reported phone line problems in the area. Phone repair scheduled for Friday, 2/18/11. Crossed phone line after repair on Sat, 2/19/11. Repair rescheduled for 2/23/11. Phone line still crossed at phone pool (behind d-mark). Will require yet another visit to fix. Scheduled for 2/25/11. Problems due to crossed wire and hung modem on PC. Crossed phone was fixed and PC was shut down and powered back on.
